Biamp LVH-900 Enhanced

The Community LVH-900 fully steerable venue horn gives integrators something no other point source can: precise, custom coverage shaped to the exact geometry of any venue. Now it’s even easier to put to work. A streamlined product line, smarter hardware, and the enhanced VenuePolar design plugin take the LVH-900 from specification to rigging faster than ever.

Simpler to Order

The “/AS” and “/AP” suffixes are no longer required when ordering. One cabinet type now serves every array, from a single cabinet to multi-cabinet systems, so specifying and quoting the right system is faster and simpler.

The LVH-900 still delivers the architecturally friendly footprint, industry-leading output, and pattern control it’s known for, from houses of worship and performing arts centres to arenas and outdoor sports venues.

Need more SPL, higher steering resolution, or low-frequency control below 200 Hz? Simply add cabinets.

Hardware Updates for Faster Installation

• One wiring scheme for every cabinet. Every cabinet uses the same wiring for 6-channel standard-resolution or 9-channel high-resolution steering. No external junction box is required.
• Simplified amp channel selection. A slide jumper on the LF1/F2 input panel switches between 9-channel (maximum resolution) and 6-channel (cost-optimized) configurations without rewiring.
• Built-in orientation cue. An off-centre input panel and debased arrow prevent inverted installation and gives riggers a clear “TOP” reference.

The Full Power of LVH-900 in Your Hands

The enhanced VenuePolar plugin for EASE Focus 3 lets designers create fully custom asymmetric coverage. It automatically determines cabinet count, splay, and aiming, then generates speaker files for Biamp ALC amplifiers.
